Selección de modelo de reductores de engranajes BKM
Solicite un presupuesto
A continuación, se encuentran las referencias de selección de modelos de la serie BKM de engranajes y reductores de engranajes:
(1)130Nm: tabla de selección de modelo de reductores de velocidad BKM-050X (n1=1400r/min)
Modelo de reductor de velocidad | i Valor nominal | i Valores reales | n2 (r/min) | M2max (Nm) | Fr2 (N) | MV63 | MV71 | MV80 | MV90 |
Etapa 3 | |||||||||
BKM0503 | 300 | 291.79 | 4.8 | 130 | 4100 | √ | |||
BKM0503 | 250 | 244.29 | 5.7 | 130 | 4100 | √ | |||
BKM0503 | 200 | 200.44 | 7.0 | 130 | 4100 | √ | |||
BKM0503 | 150 | 146.67 | 9.5 | 130 | 4000 | √ | |||
BKM0503 | 125 | 120.34 | 11.6 | 130 | 3770 | √ | √ | ||
BKM0503 | 100 | 101.04 | 13.9 | 100 | 3560 | √ | √ | ||
BKM0503 | 75 | 74.62 | 18.8 | 80 | 3220 | √ | √ | ||
BKM0503 | 60 | 62.36 | 22 | 130 | 3030 | √ | √ | ||
BKM0503 | 50 | 52.36 | 27 | 100 | 2860 | √ | √ | ||
Etapa 2 | |||||||||
BKM0502 | 60 | 58.36 | 24 | 130 | 2960 | √ | √ | ||
BKM0502 | 50 | 48.86 | 29 | 130 | 2790 | √ | √ | ||
BKM0502 | 40 | 40.09 | 35 | 130 | 2610 | √ | √ | ||
BKM0502 | 30 | 29.33 | 48 | 130 | 2350 | √ | √ | √ | |
BKM0502 | 25 | 24.07 | 58 | 130 | 2200 | √ | √ | √ | |
BKM0502 | 20 | 20.21 | 69 | 100 | 2080 | √ | √ | √ | |
BKM0502 | 15 | 14.92 | 94 | 80 | 1880 | √ | √ | √ | |
BKM0502 | 12.5 | 12.47 | 112 | 130 | 1770 | √ | √ | √ | √ |
BKM0502 | 10 | 10.47 | 134 | 100 | 1670 | √ | √ | √ | √ |
BKM0502 | 7.5 | 7.73 | 181 | 80 | 1510 | √ | √ | √ | √ |
200Nm: BKM-063X speed reducer model selection table (n1=1400r/min)
Modelo de reductor de velocidad | i Valor nominal | i Valores reales | n2 (r/min) | M2max (Nm) | Fr2 (N) | MV63 | MV71 | MV80 | MV90 |
Etapa 3 | |||||||||
BKM0633 | 300 | 302.50 | 4.6 | 200 | 4800 | √ | |||
BKM0633 | 250 | 243.57 | 5.7 | 200 | 4800 | √ | |||
BKM0633 | 200 | 196.43 | 7.1 | 180 | 4800 | √ | |||
BKM0633 | 150 | 151.56 | 9.2 | 200 | 4650 | √ | √ | ||
BKM0633 | 125 | 122.22 | 11.5 | 180 | 4330 | √ | √ | ||
BKM0633 | 100 | 101.27 | 13.8 | 150 | 4070 | √ | √ | ||
BKM0633 | 75 | 73.33 | 19.1 | 110 | 3650 | √ | √ | ||
BKM0633 | 60 | 63.33 | 22 | 180 | 3480 | √ | √ | √ | |
BKM0633 | 50 | 52.48 | 27 | 150 | 3270 | √ | √ | √ | |
Etapa 2 | |||||||||
BKM0632 | 60 | 60.50 | 23 | 200 | 3430 | √ | √ | √ | |
BKM0632 | 50 | 48.71 | 29 | 200 | 3190 | √ | √ | √ | |
BKM0632 | 40 | 39.29 | 36 | 180 | 2970 | √ | √ | √ | |
BKM0632 | 30 | 30.31 | 46 | 200 | 2720 | √ | √ | √ | √ |
BKM0632 | 25 | 24.44 | 57 | 180 | 2530 | √ | √ | √ | |
BKM0632 | 20 | 20.25 | 69 | 150 | 2380 | √ | √ | √ | |
BKM0632 | 15 | 14.67 | 95 | 110 | 2130 | √ | √ | √ | |
BKM0632 | 12.5 | 12.67 | 110 | 180 | 2030 | √ | √ | ||
BKM0632 | 10 | 10.50 | 133 | 150 | 1910 | √ | √ | ||
BKM0632 | 7.5 | 7.60 | 184 | 110 | 1710 | √ | √ |
350Nm: BKM-075X speed reducer model selection table (n1=1400r/min)
Modelo de reductor de velocidad | i Valor nominal | i Valores reales | n2 (r/min) | M2max (Nm) | Fr2 (N) | MV63 | MV71 | MV80 | MV90 | MV100 | MV112 |
Etapa 3 | |||||||||||
BKM0753 | 300 | 297.21 | 4.7 | 350 | 6500 | √ | √ | ||||
BKM0753 | 250 | 240.89 | 5.8 | 350 | 6500 | √ | √ | ||||
BKM0753 | 200 | 200.66 | 7.0 | 300 | 6500 | √ | √ | ||||
BKM0753 | 150 | 151.20 | 9.3 | 350 | 6500 | √ | √ | √ | |||
BKM0753 | 125 | 125.95 | 11.1 | 300 | 5980 | √ | √ | √ | |||
BKM0753 | 100 | 99.22 | 14.1 | 240 | 5520 | √ | √ | √ | |||
BKM0753 | 75 | 75.45 | 18.6 | 200 | 5040 | √ | √ | √ | |||
BKM0753 | 60 | 62.43 | 22 | 300 | 4730 | √ | √ | √ | |||
BKM0753 | 50 | 49.18 | 28 | 240 | 4370 | √ | √ | √ | |||
Etapa 2 | |||||||||||
BKM0752 | 60 | 59.44 | 24 | 350 | 4660 | √ | √ | √ | |||
BKM0752 | 50 | 48.18 | 29 | 350 | 4340 | √ | √ | √ | |||
BKM0752 | 40 | 40.13 | 35 | 300 | 4080 | √ | √ | √ | |||
BKM0752 | 30 | 30.24 | 46 | 350 | 3720 | √ | √ | √ | |||
BKM0752 | 25 | 25.19 | 56 | 300 | 3500 | √ | √ | √ | |||
BKM0752 | 20 | 19.84 | 71 | 240 | 3230 | √ | √ | √ | |||
BKM0752 | 15 | 15.09 | 93 | 200 | 2950 | √ | √ | √ | |||
BKM0752 | 12.5 | 12.49 | 112 | 300 | 2770 | √ | √ | √ | |||
BKM0752 | 10 | 9.84 | 142 | 240 | 2550 | √ | √ | √ | |||
BKM0752 | 7.5 | 7.48 | 187 | 200 | 2330 | √ | √ | √ |
500Nm: BKM-090X speed reducer model selection table (n1=1400r/min)
Modelo de reductor de velocidad | i Valor nominal | i Valores reales | n2 (r/min) | M2max (Nm) | Fr2 (N) | MV63 | MV71 | MV80 | MV90 | MV100 | MV112 |
Etapa 3 | |||||||||||
BKM0903 | 300 | 295.18 | 4.7 | 500 | 8300 | √ | √ | ||||
BKM0903 | 250 | 240.89 | 5.8 | 500 | 8300 | √ | √ | √ | |||
BKM0903 | 200 | 200.66 | 7.0 | 480 | 8300 | √ | √ | √ | |||
BKM0903 | 150 | 151.20 | 9.3 | 500 | 8050 | √ | √ | √ | |||
BKM0903 | 125 | 125.95 | 11.1 | 480 | 7580 | √ | √ | √ | √ | ||
BKM0903 | 100 | 99.22 | 14.1 | 380 | 7000 | √ | √ | √ | √ | ||
BKM0903 | 75 | 75.45 | 18.6 | 300 | 6390 | √ | √ | √ | √ | ||
BKM0903 | 60 | 62.43 | 22 | 480 | 6000 | √ | √ | √ | |||
BKM0903 | 50 | 49.18 | 28 | 380 | 5540 | √ | √ | √ | |||
Etapa 2 | |||||||||||
BKM0902 | 60 | 59.04 | 24 | 500 | 5890 | √ | √ | √ | |||
BKM0902 | 50 | 48.18 | 29 | 500 | 5500 | √ | √ | √ | |||
BKM0902 | 40 | 40.13 | 35 | 480 | 5170 | √ | √ | √ | |||
BKM0902 | 30 | 30.24 | 46 | 500 | 4710 | √ | √ | √ | |||
BKM0902 | 25 | 25.19 | 56 | 480 | 4430 | √ | √ | √ | √ | ||
BKM0902 | 20 | 19.84 | 71 | 380 | 4090 | √ | √ | √ | √ | ||
BKM0902 | 15 | 15.09 | 93 | 300 | 3730 | √ | √ | √ | √ | ||
BKM0902 | 12.5 | 12.49 | 112 | 480 | 3510 | √ | √ | √ | |||
BKM0902 | 10 | 9.84 | 142 | 380 | 3240 | √ | √ | √ | |||
BKM0902 | 7.5 | 7.48 | 187 | 300 | 2950 | √ | √ | √ |
750Nm: BKM-110X speed reducer model selection table (n1=1400r/min)
Modelo de reductor de velocidad | i Valor nominal | i Valores reales | n2 (r/min) | M2max (Nm) | Fr2 (N) | MV63 | MV71 | MV80 | MV90 | MV100 | MV112 |
Etapa 3 | |||||||||||
BKM1103 | 300 | 296.10 | 4.7 | 750 | 10000 | √ | √ | ||||
BKM1103 | 250 | 244.29 | 5.7 | 750 | 10000 | √ | √ | ||||
BKM1103 | 200 | 206.29 | 6.8 | 750 | 9920 | √ | √ | ||||
BKM1103 | 150 | 153.33 | 9.1 | 750 | 8980 | √ | √ | √ | |||
BKM1103 | 125 | 129.48 | 10.8 | 750 | 8490 | √ | √ | √ | |||
BKM1103 | 100 | 103.64 | 13.5 | 650 | 7880 | √ | √ | √ | |||
BKM1103 | 75 | 75.55 | 18.5 | 520 | 7090 | √ | √ | √ | |||
BKM1103 | 60 | 64.18 | 22 | 750 | 6720 | √ | √ | √ | |||
BKM1103 | 50 | 51.37 | 27 | 650 | 6240 | √ | √ | √ | |||
Etapa 2 | |||||||||||
BKM1102 | 60 | 59.22 | 24 | 750 | 6540 | √ | √ | √ | |||
BKM1102 | 50 | 48.86 | 29 | 750 | 6130 | √ | √ | √ | |||
BKM1102 | 40 | 41.26 | 34 | 750 | 5800 | √ | √ | √ | |||
BKM1102 | 30 | 30.67 | 46 | 750 | 5250 | √ | √ | √ | |||
BKM1102 | 25 | 25.90 | 54 | 750 | 4960 | √ | √ | √ | √ | ||
BKM1102 | 20 | 20.73 | 68 | 650 | 4610 | √ | √ | √ | √ | ||
BKM1102 | 15 | 15.11 | 93 | 520 | 4150 | √ | √ | √ | √ | ||
BKM1102 | 12.5 | 12.84 | 109 | 750 | 3930 | √ | √ | √ | |||
BKM1102 | 10 | 10.27 | 136 | 650 | 3650 | √ | √ | √ | |||
BKM1102 | 7.5 | 7.49 | 187 | 520 | 3280 | √ | √ | √ |
Nota: √ Indica que la combinación de motor eléctrico y redactor de velocidad se encuentra disponible, mientras que en blanco significa que la combinación no se encuentra disponible.
