Duplex TDF Flange Forming Machine
Our duplex TDF roll former can form TDF lock on both side of duct simultaneously, increasing productivity and improving the aesthetics of the finished product.
High precision, rigid, reliable, high load straight guiding rail thus achieving great mobility.
Adjustable mid gap, ranging between 1000- 1250m
Parámetros:| Type | 2-SBTDF-12 | 2-SBTDF-15 |
| Width | 600-1600mm | 600-1600mm |
| Thickness | 0.6-1.2mm | 1.0-1.5mm |
| Roller Shape | ||
| A-Size | 33±0.5mm | 35±0.5mm |
| Motor | 5.5Kw | 5.5Kw |
| Weight | 1000Kg | 1500Kg |
| Dimension | 2500×2600×1200mm | 2800×2600×1250mm |
